阿里云块存储团队软件工程实践

#define THROTL_UNSET      -2#define THROTL_NO_LIMIT   -1bool throttle_is_quota_valid(int64_t value){    // 复杂的判断条件    // 请你在三秒内说出 value 如何取值是合法的？    if (value < 0 && value != THROTL_UNSET && value != THROTL_NO_LIMIT)    {        return false;    }    return true;}bool throttle_is_quota_valid(int64_t value){    // 这是修改后的代码，value 取值合法有三种情况，一目了然    return value >= 0 || value == THROTL_UNSET || value == THROTL_NO_LIMIT;}

void RecycleBin::Load(BindCallbackR1<Status>* done){    ......    FOREACH(iter, fileStats)    {        RecycleFile item;        Status status = ParseDeletedFileName(iter->path, &item.timestamp);        if (!status.IsOk() { ...... }        item.fileName = iter->path;        item.size = iter->size;        item.physicalSize = iter->refCount > 1 ? 0 : iter->physicalSize;        ......        // 这是修改前的代码        // earliestTimestamp[item.medium] =        //     item.timestamp != 0 && item.timestamp < earliestTimestamp[item.medium] ?        //     item.timestamp : earliestTimestamp[item.medium];        // }        // 这是修改后的代码        if (item.timestamp != 0 &&            item.timestamp < earliestTimestamp[item.medium])        {            earliestTimestamp[item.medium] = item.timestamp;        }    }    ......}

Status Foo(){    Status status = Check1();    if (!status.IsOk())    {        return status;    }    else    {        status = Check2();        if (!status.IsOk())        {            return status;        }        else        {            status = Check3();            if (!status.IsOk())            {                return status;            }            else            {                DoSomeRealWork();                return OK;            // 四层潜套 if            }        }    }}

Status Foo(){   Status status = Check1();   if (!status.IsOk())   {       return status;   }   status = Check2();   if (!status.IsOk())   {       return status;   }   status = Check3();   if (!status.IsOk())   {       return status;   }   DoSomeRealWork();   return OK;}

void Foo(RpcController* ctrl,         const FooRequest* request,         FooResponse* response,         Closure* done){    Status status = Check1(request);    if (!status.IsOk())    {        response->set_errorcode(status.Code());        // 第一处        done->Run();        return;    }    status = Check2(request);    if (!status.IsOk())    {        response->set_errorcode(status.Code());        // 第二处        done->Run();        return;    }    DoSomeRealWork(...);    // 第三处    done->Run();}

void Foo(RpcController* ctrl,         const FooRequest* request,         FooResponse* response,         Closure* _done){    // 仅一处，不遗漏    erpc::ScopedCallback done(_done);    Status status = Check1(request);    if (!status.IsOk())    {         response->set_errorcode(status.Code());         return;    }    status = Check2(request);    if (!status.IsOk())    {         response->set_errorcode(status.Code());         return;    }    DoSomeRealWork(...);}

void CompactTask::checkFileUtilizationRewrite(){    // 此处采取朴素的排序算法，并未采取更高效的 TopK 算法    std::sort(sealedFilesUsage.begin(), sealedFilesUsage.end(), GarbageCollectionCompare);    int64_t sealedFileMaxSize = INT64_FLAG(lsm_CompactionSealedMaxSize);    int32_t sealedFileMaxNum = INT32_FLAG(lsm_CompactionSealedMaxFileNum);    int64_t targetFileSize = 0;    int32_t sourceFileCnt = 0;                                                                                                                                          // 前者简单清淅，并在几十个 File 中选择前几个文件的场景并不算太慢    FOREACH(itr, sealedFilesUsage)    {        LogicalFileId fileId = itr->fileId;        const FileUsage* usage = baseMap->GetFileUsage(fileId);        const File* file = fileSet->GetFile(fileId);        targetFileSize += usage->blocks * mBlockSize;        sourceFileCnt++;        if (targetFileSize > sealedFileMaxSize || sourceFileCnt > sealedFileMaxNum)        {            break;        }        mRewriteSealedFiles[fileId] = true;    }    ......}

void UserRequestControl::WaitForPendingIOs(){    erpc::ExponentialBackoff delayTimeBackOff;    delayTimeBackOff.Reset(            INT64_FLAG(lsm_UnloadWaitingBackoffBaseUs),            INT64_FLAG(lsm_UnloadWaitingBackoffLimitUs),            INT64_FLAG(lsm_UnloadWaitingBackoffScaleFactor));    // 轮循等待在途的请求返回    // 请思考如何用条件变量实现精确的同步    while (!mWriteQueue.empty()|| !mReadQueue.empty())    {        uint64_t delayTime = delayTimeBackOff.Next();        PGLOG_INFO(sLogger,                  (__FUNCTION__, "Waiting for inflight requests during segment unload")                  ("Segment", mSegment->GetName())                  ("Write Requests", mWriteQueue.size())                  ("ReadRequests", mReadQueue.size())                  ("DelayTimeInUs", delayTime));        easy_coroutine_usleep(delayTime);  // 退避等待    }}

pthread_mutex_t mutex;pthread_cond_t  nonEmptyCondition;std::list<Task*> queue;void ConsumerLoop(){    pthread_mutex_lock(&mutex);    while (true)    {        while (queue.empty())        {            struct timespec ts;            ts.tv_sec = 1;            ts.tv_nsec = 0;            // 使用timewait            pthread_cond_timedwait(&nonEmptyCondition, &mutex, timespec);        }        Task* firstTask = queue.front();        queue.pop_front();        consume(firstTask);    }    pthread_mutex_unlock(&mutex);}

// load.cppStatus LoadTask::Execute(){    Status status;#define RUN_STEP(func) \    status = func();    if (!status.IsOk()) { ... }    // 串行执行下列步骤    RUN_STEP(doPrepareDirs);    ...... // 十几步    RUN_STEP(doTask);#undef RUN_STEP    ......}// files.cppStatus FileMap::SealFilesForLiveDevice(){    Status status = OK;    std::vector<SyncClosureR1<Status>*> sealDones;    STLDeleteElementsGuard<std::vector<SyncClosureR1<Status>*> >        donesDeleter(&sealDones);    // 并行 seal 每个文件    FOREACH(iter, mActiveFiles)    {        File* file = iter->second;        sealDones.push_back(new SyncClosureR1<Status>());        Closure* work = stone::NewClosure(                this,                &FileMap::doSealFileForLiveDevice,                file,                static_cast<BindCallbackR1<Status>*>(sealDones.back()));        InvokeCoroutineInCurrentThread(work);    }    // 收集结果    FOREACH(done, sealDones)    {        (*done)->Wait();        if (!(*done)->GetResult0().IsOk())        {            status = (*done)->GetResult0();        }    }    return status;}

// stream.hclass Stream{public:    Stream();    ~Stream();    void Read(ReadArgs* args);    ......private:    // 增加 magic 字段    // 通常使用 uint32 或 uint64    uint64_t mObjectMagic;    ......};// stream.cpp// 定义 magic 常量// 常量值选择 hexdump 时能识别的字符串，以便在 gdb 查看 coredump 时快速识别// 此处使用 “STREAM” 的 ASCII 串static uint64_t STREAM_OBJECT_MAGIC = 0x4e4d474553564544LL; Stream::Stream()  : mObjectMagic(STREAM_OBJECT_MAGIC)  // 在构造函数中赋值{    ......}Stream::~Stream(){    // 在析构函数中检查并破坏 magic 字段，预防 double-free 错误    easy_assert(mObjectMagic == STREAM_OBJECT_MAGIC);    mObjectMagic = FREED_OBJECT_MAGIC;    ......}void DeviceSegment::Read(ReadArgs* args){    // 在重要的函数中检查 magic 字段，预防 use-after-free 错误    easy_assert(mObjectMagic == DEVICE_SEGMENT_OBJECT_MAGIC);    ......  }

class StreamWriter{public:    ......private:    struct StreamGroup    {        WriteAttemptList failureQueue;        WriteAttemptList inflightQueue;        WriteAttemptList pendingQueue;        uint64_t         commitSeq;        uint64_t         lastSeq;    };    uint32_t     mStreamGroupCount;    StreamGroup  mStreamGroups[STREAM_GROUP_COUNT];        ......};void StreamWriter::sanityCheck(){#ifndef NDEBUG  // expensive checks    for (uint32_t i = 0; i < mStreamGroupCount; i++)    {        // Check that sequence in "failureQueue", "inflightQueue" and "pendingQueue" are ordered.        const StreamGroup* group = &mStreamGroups[i];        uint64_t prevSeq = group->commitSeq;        const WriteAttemptList* queues[] = {            &group->failureQueue,            &group->inflightQueue,            &group->pendingQueue        };        for (size_t k = 0; k < easy_count_of(queues); k++)        {            FOREACH(iter, *queues[k])            {                const WriteRequest* write = iter->write;                PANGU_ASSERT(prevSeq <= write->seq); // SanityCheck                prevSeq = write->seq + write->lbaRange.rangeSize;            }        }        ASSERT(prevSeq == group->lastSeq); // SanityCheck    }    ......#endif  // NDEBUG}

Status LoadTask::doTailScanFiles(){    ......    for (id = FIRST_REAL_FILE_ID; id < mFileSet->GetTotalFileCount(); id++)    {        File* file = mDiskFileSet->GetFile(id);        if (file->GetLogicalLength() < logicalLengthInIndex)        {             const char* msg = “BUG!! Found a data on disk with shorter length ”                               “than in map. This is probably caused by length reduction of ”                               “that file.”;   // 记录详细的日志，包括文件名、期望长度、实际长度等             PGLOG_FATAL(sLogger, (__FUNCTION__, msg)                         (“Stream”, mStream->GetName())                         (“File”, file->GetFileName())                         (“FileId”, file->GetFileId())                         (“FileLengthOnDisk”, file->GetFileLength())                         (“FileLengthInIndex”, physicalLengthInIndex)                         (“LogicalLengthOnDisk”, file->GetLogicalLength())                         (“LogicalLengthInIndex”, logicalLengthInIndex)                         (“MissingSize”, physicalLengthInIndex - file->GetFileLength()));             SERVICE_ADD_COUNTER(“LSM:CriticalIssueCount”, 1);  // 触发电话告警             return LSM_FILE_CORRUPTED;        }    }}

linux/include/linux/jiffies.h/*•* Have the 32 bit jiffies value wrap 5 minutes after boot* so jiffies wrap bugs show up earlier.*/#define INITIAL_JIFFIES ((unsigned long)(unsigned int) (-300*HZ))/** These inlines deal with timer wrapping correctlyYou are•* strongly encouraged to use them* 1. Because people otherwise forget* 2. Because if the timer wrap changes in future you won't have to* alter your driver code.** time_after(a,b) returns true if the time a is after time b.*/#define time_after(a,b) \    (typecheck(unsigned long, a) && \    typecheck(unsigned long, b) && \    ((long)((b) - (a)) < 0))

// easy/src/io/easy_timer.h// ----------------------------------------------------------------------------------// following interface, use easy_timer_sched from th(io thread or worker thread),// ** DON NOT support async call **//int easy_timer_start_on_th(easy_baseth_t *th, easy_timer_t *timer);int easy_timer_stop_on_th(easy_baseth_t *th, easy_timer_t *timer);

TEST_F(..., SharedDisk_StopOneBs)(...) {    BenchMarkStart(mOption);    // for循环反复注入    mCluster->StopServer(0);    mCluster->StartServer(0);    // 修复前无第12行无代码，无下限检查，全部失败时Case PASS    // 共享盘开盘后线程死锁必IO Hang，有测试无断言遗漏Bug导致P1故障    EXPECT_GT(mIoBench->GetLastPrintIops(), 0);    EXPECT_GT(mIoBench->GetMaxLatency(), 0);    // 断言检查，边界上限    EXPECT_GT(20 * 1000000, mIoBench->GetMaxLatency());    // Do something below}Status PRConfig::Register )(...){     assertIoThread();     // 修复前缺少=，导致Sever Crash     if (unlikely(mRegistrants.size() >= MAX_REGISTRANT_NUM))    {        LOG_ERROR(...);        return SC_RESERVATION_CONFLICT;    }    // Do something below}

void WalStreamWriterPool::tryCreateWalWriter(){    AssertCoroutine();    ASSERT_DEBUG(mIsCreating);    Status status = OK;    while (...)    {        WalStreamWriter *writer = mWalManager->CreateWalWriter();        status = writer->Open();        // 修复前无第14行代码部分，未处理Commit，失败导致丢掉WAL文件，进而丢数据        if (status.IsOk())        {            status = mWalManager->Commit();        }        // Do something below}void RPCController::StartCancel(){    if (_session) {        if (_pendingRpc != NULL) {            // 修复前无第29行代码，线程Hang进而IOHang            // 未测试覆盖call StartCancel  before handshake            _session->need_cancel = true;        } else {            easy_session_cancel(_session);        }    } else {        easy_error_log(...);    }}

Status CompressOffsetTable::Seal(){    // Do something before    status = mTableFile->Seal();    if (!status.IsOk())    {        PGLOG_ERROR(...);        return status;    }    mIsSealed = true;    // 修复前无第14行代码，文件写入已完成，清空缓存，释放内存    mEasyPool.reset();    // Do something below}

void ActiveManager::SubmitIO({     // 【版本兼容性】 SDK 和 Server线程不对齐，旧版本SDK不支持切线程     if (UNLIKELY(GetCurrentThread() != serverThread))     PGLOG_WARNING(...  "Server thread mismatch");     response->ErrorCode = SERVER_BUSY;     done->Run();}void ChunkListAccessor::SetChunkInfoAndLocations(){    uint8_t flags = mFileNodePtr->fileFlags;    bool isLogFile = IsFlatLogFile(flags);    ASSERT(        //【协议兼容性】Master 和 SDK异常场景定长误判        (isLogFile && vecChunkInfoNode[0].version <= masterChunkInfo.version) ||        !isLogFile);         // Do something below}// 【API兼容性】 Server 和 Master的错误码不一致，数据分片反复加载/卸载// Master侧，device_load.cpp// if(status.Code() == LSM_SEGMENT_EXIST_OTHER_VERSION))// Server侧，device_load.cpp// return LSM_NOT_OWN_SEGMENT;

TEST_F(FastPathSmokeTestFixture, Resize){    // ... Do something    ResizeVolume(uri, DEVICE_SIZE * 2);    Status status = OK;    do {        // 状态依赖，未检查resize 是否成功，导致错误的认为是越界io处理        status = Write(handle, wbuf.get(), 0, 4096);        if (status.Code() == OK)        {            break;        }        easy_coroutine_usleep(100*1000);    } while(1);    // ... Do something}// volume_iov_split_test.cppTEST(VolumeIovSplitTest, Iovsplit_Random){    // ... Do something    size_t totalLength = 0;    // 修改前无+1，0是非法随机值，造成Case低概率失败    totalLength = rand() % (10*1024*1024) + 1    // ... Do something}
